Airframe

5 Cell Operation

*6 Cell Operation

Wingspan

150in

150in

Weight

10lb 8oz

10lb 12oz

Wing Area

1710sq ins

1710sq ins

Wing Loading

14.2oz/sq ft

14.48oz/sq ft

Power System

Motor

Turnigy 50-55A 400kv

Turnigy 50-55A 400kv

Battery

5 x 3000mah LiPo

6 x 3300mah LiPo

Propeller

15 x 10in

15 x 10in

Performance

Power loading

77W/lb

103.3W/lb

Calculated Thrust

8lb 7oz

11lb 4oz

*Note that the model is more than adequately powered on a 5s battery. The move to 6s operation was motivated by a desire to rationalise my battery usage.



There is also a build thread for this model on RCGroups
