(Built from Clancy Aviation kit)

This model was originally built with interchangeable motor pods (see Review Article for more details). However, the Speed 400 version was soon abandoned.



After 13 years and nearly 400 flights the Lazy Bee was looking a little tatty so it was time to bring it into the brushless age - see last column of figures below.



Click here for more details of the refurbishment and motor upgrade.

Kyosho Car Motor

Geared Speed 400

*Brushless Upgrade

Airframe

Wingspan

48in

48in

48in

Weight

2lb 10oz

1lb 12oz

2lb 5oz

Wing Area

630 sq ins

630 sq ins

630 sq ins

Wing Loading

9.6oz/sq ft

6.4oz/sq ft

8.5oz/sq ft

Power System

Motor

Kyosho 480T

Graupner 7.2v Speed 400

XYH35-36 1300kv

Gear Ratio

Olympus 2.3:1 Belt Drive

Graupner 1.5:1

Direct Drive

Battery

7 x 1700mah NiCd

7 x 500mah NiCd

3 x 3700mah LiPo

Propeller

Master Airscrew 9" x 4"

Master Airscrew 9" x 6"

APC E 9" x 4.5"

Performance

8400rpm at 14.7amps

Not measured

10300rpm at 23.8amps

Power loading

44W/lb

Not measured

100W/lb

Calculated Thrust

1lb 6oz

Not measured

2lb 1oz


*For details of brushless upgrade, click here
